Male Female thread SS Braided Flexible Hose

Products Category : Female Male Thread Flexible Hose

Details

Male Female thread SS Braided Flexible Hose

SS braided flexible hose is a flexible pipe element, used to transport cooling water, natural gas, oil, steam, engine exhaust and other media. Compared with other pipes, its main advantages are wear resistance and pressure resistance, and can inhibit vibration, compensate for position offset, Angle offset. Stainless steel braided flexible hose are not susceptible to high temperature and high pressure, have a certain corrosion resistance, and can work in harsh environments.

Male Female thread ss braided flexible hose construction:

metal corrugated hose, braided mesh layer, collars and female x male thread fittings.

Thread Braided Flexible Hose.jpg BSP Female thread ss flexible hose.jpg 60 degree Taper seal BSP flexible hose.jpg

Male Female thread SS Braided Flexible Hose Parameters:

1. Connect type: male thread x female thread

2. Hose material: stainless steel 304 or 316, 321

3. Hose size: 6-100mm

4. Hose type: annular corrugated or spiral corrugated

5. Braided wire material: stainless steel 304 or 316

6. Thread standard: BSP, NPT, Metric, JIC

7. SS braided flexible hose length: 0.2m-10m or according to your request

SS Braided Flexible Hose.jpg Male Female thread SS Flexible Hose.jpg Male Female thread SS Braided Flex Hose.jpg

Male Female thread SS Braided Flexible Hose applications:

Power industry, Iron and steel industry, Chemical industry, Oil refining industry, Cement industry, Ships and Marine industries, Instrument industry, Diesel exhaust system, Oil and gas transportation, Thermal pipe network, Renewable energy, Water treatment and wastewater treatment, Pharmaceutical industry, Measurement and control system, Vacuum and high vacuum system, Pulp and paper industry.

ss flexible hose application.jpg
