Flange stainless steel flexible metal hose
These flange stainless steel flexible metal hoses are braided to give strength when the hose is pressurized and to provide a solid protective cover during use. Typical materials such as 316L and 321 stainless steel can withstand extreme variations in temperature, from cryogenic up to 1500°F (815°C). Multiple braided layers can increase working pressure as well as with corrugation shape, profile, wall thickness and material type. With differing engineering techniques involved and excellent burst strength-to-wall thickness ratio, these flexible braided metal hoses are relatively lightweight compared to equivalent non-metallic hose alternatives in the market.
The flange flexible metal hose consists of metal corrugated hose, braided mesh layer and floating, floating or fixed flange ends.
Flange flexible metal hose technical data:
1 Hose material: SS304 or SS316L (SS321 also available)
2 Braided mesh material: SS304, SS316
3 Hose size: 1/2"-24"(DN15-600mm)
4 Hose type: annular or spiral corrugated
5 Connect type: floating or fixed flange
6 Flange standard: ANSI, ASME B16.5, JIS, DIN, GOST, BS, GB, Table E, etc
7 Maximum working pressure: 10Mpa
8 Braided mesh layer: one or double layer braided mesh
9 Operating temperature range: -200℃ to +500℃ (Special specifications up to 1000℃)
10 Flange material: carbon steel or stainless steel
Flange flexible metal hose feature:
Heat, Pressure-Induced Expansion and Defection Absorption, Handle Vibration, Compensate Misalignment, Allow Axial and Lateral Displacement
Flange flexible metal hose assembly application:
Mainly used in Chemical Processing, Steel Mill, Petrochemical, Paper & Pulp, HVAC, Power Generation, Pump Connectors, Mining, Exhaust, Cryogenics and Refrigeration, Air Compressors, Food Processing, oil and Gas, etc.
We can provide flange flexible metal hose samples for testing.
The minimum order quantity of flange stainless steel flexible metal hose is 1 pcs.
As a professional flange flexible metal hose manufacturer, Dinghong is based on a welding team with more than 15 years of production experience and strong technical ability. Continuously improve the production process in the production, to provide customers with high-quality and reliable flange metal hose assembly.
